UL-Certified BOPI Film with Extreme Temperature Stability, Outstanding Mechanical Properties, and Superior Electrical Insulation

Name: UL-Certified BOPI Film with Extreme Temperature Stability, Outstanding Mechanical Properties, and Superior Electrical Insulation
Brand: UN.Tex (Dalian) Co.,Ltd
SKU: 6052
Price: 3.00 USD
Availability: InStock

Alle Produkte

Klebendes Isolierungs-Band
(114)

Glasgewebe-Isolierungs-Band
(59)

Hitzebeständiges Isolierungs-Band
(43)

Glasgewebe-Klebstreifen
(33)

Polyimide-Film-Klebstreifen
(47)

Aluminiumfolie-Klebstreifen
(67)

Aluminiumfolie-Glasgewebe-Band
(11)

Folienbeschichtetes Kraftpapier
(15)

Aluminiumfolie-Fiberglas-Stoff
(22)

Folien-Baumwollstoff-Band
(13)

Stoff-Panzerklebeband
(24)

Doppeltes mit Seiten versehener Klebstreifen
(9)

HAUSTIER Klebstreifen
(7)

Präzisions-Feinguss
(49)

Elektrische Isolationsplatte
(37)

Beste Produkte

Beständiger Polyimide-elektrisches Isolierungs-Band der hohen Temperatur

Elektrisches Band der Isolierung Polyimide-hohen Temperatur

H-Grad Polyimide-Film-Klebstreifen

Bescheinigung

CHINA UN.Tex (Dalian) Co.,Ltd zertifizierungen

Ich bin online Chat Jetzt

UL-Certified BOPI Film with Extreme Temperature Stability, Outstanding Mechanical Properties, and Superior Electrical Insulation

Großes Bild : UL-Certified BOPI Film with Extreme Temperature Stability, Outstanding Mechanical Properties, and Superior Electrical Insulation

Produktdetails:

Herkunftsort:	CHINA
Zertifizierung:	UL
Modellnummer:	6052

Zahlung und Versand AGB:

Min Bestellmenge:	1 Roll
Preis:	basing as thickness and quantity
Verpackung Informationen:	Karton und Palette
Lieferzeit:	ungefähr 15 Tage
Zahlungsbedingungen:	T/t
Versorgungsmaterial-Fähigkeit:	1.000.000 qm pro Monat

Kontakt

UL-Certified BOPI Film with Extreme Temperature Stability, Outstanding Mechanical Properties, and Superior Electrical Insulation

Beschreibung

Material:	Biaxial orientierte Polyimidfolie (BOPI-Folie)	Dicke:	7.5 bis 50 mm
Dehnfestigkeit (longitudinal):	≥150Mpa	Dehnfestigkeit (quer):	≥150Mpa
Bruchdehnung (längs):	≥ 40%	Bruchdehnung (quer):	≥ 40%
Wechselfrequenz-elektrische Festigkeit (Mittelwert):	≥220	Leistungsfrequenz elektrische Stärke (individueller Wert):	≥ 150
Oberflächenwiderstand:	≥1,0×10 14Ω	Volumetrischer Widerstand:	≥ 1,0 × 10 10Ωm
Hervorheben:	Extreme Temperature Stability BOPI Film , Outstanding Mechanical Properties Polyimide Film , Superior Electrical Insulation Polyimide Film Adhesive Tape

UL-Certified, Dual-Side Corona Treated BOPI Film For Extreme Temperatures

The high-performance, industrial-grade biaxially oriented polyimide (BOPI) film is engineered for demanding applications, delivering exceptional thermal stability, mechanical strength, and reliable electrical insulation. Through specialized biaxial orientation, the film achieves superior dimensional integrity and durability, with both surfaces receiving precisely controlled corona treatment for excellent adhesion.

Product Specifications

Attribute	Value
Material	Biaxially Oriented Polyimide Film (BOPI Film)
Thickness	7.5~50μm
Tensile strength (longitudinal)	≥150MPa
Tensile strength (transverse)	≥150MPa
Break elongation (longitudinal)	≥40%
Break elongation (transverse)	≥40%
Power frequency electrical strength (average value)	≥220
Power frequency electrical strength (individual value)	≥150
Surface resistivity	≥1.0×10¹⁴Ω
Volumetric resistivity	≥1.0×10¹⁰Ωm

Key Properties

Extreme Temperature Stability: Exceptional resistance to high and low temperatures with high glass transition temperature (Tg).
Outstanding Mechanical Properties: High tensile strength, tear resistance, rigidity, and dimensional stability under stress.
Superior Electrical Insulation: Reliable dielectric material for demanding electrical applications.
Excellent Chemical Resistance: Resistant to organic solvents, oils, greases, and other chemicals.
Inherent Flame Retardancy: Self-extinguishing properties compliant with strict flame-retardancy standards.

Applications

Heat-Resistant Heaters & Sensors: Durable, thermally stable dielectric and protective layer for flexible heating elements and sensor arrays.
High-Temperature Barrier & Release Films: Ideal for processing environments requiring thermal resilience.
EMI Shielding: Robust substrate for metallized shielding films that block electromagnetic interference.

This UL-certified, dual-side corona-treated BOPI film offers manufacturers a robust, high-performance material solution with exceptional process compatibility and product dependability.
